Hydraulic Wheel Loader Machine Max.Dump Clearance 3200mm
1. Products Description of MCLLROY Wheel Loader
In general, for construction machinery, the four most important factors are: price, quality, operation, and after-sales.
The amount of shovel material and the stability of the loader depend on the cooperation of the loader frame.
The flexibility and light operation mainly depends on the hydraulic system of the loader.
The low failure rate depends on quality as well as the after-sales service.
MCLLROY wheel Loaders are widely used in the construction, municipal engineering, urban and rural gardens, lime, sand, cement factories, mines and other enterprises and institutions and departments. It is particularity applied to the narrow space for the loading operation of stone,sand and other construction materials.
2. Specification of MCLLROY Wheel Loader
| MSL930/ZL930 | Metric Units |
| Engine Model | Changfa 490 /Yun Nei 490 |
| RPM | 2400 |
| Rated Power | 42 kW |
| Emissions | EU Stage II |
| Operating Weight | 3200 kg |
| Rated Load | 2000 kg |
| Bucket Capacities | 1.0 m³ |
| Max. Travel Speed | 35 km/h |
| Gear Box | CVT
265 torque converter |
| Axle | Isuzu |
| Axle Base | 2300 mm |
| Brake | Disc Brake |
| Hydraulic Cycle time - lift | ≤ 7 s |
| Min. Ground Clearance | 260 mm |
| Wheel Base | 1800 mm |
3.Details and advantages of MCLLROY Wheel Loader
The enhanced front and rear frames are proved by 100,000-cycle reliability test.
The lower hinge joint is upgraded from knuckle bearings to tapered roller bearings to prolong the life by 50%.
The wheelbase of the rear frame is extended to enhance the stability and tipping load of the whole machine.
New designed axle with thicker shell.
Oil tube is connected in priority valve in non-rotated form,which prevents the oil tube from cracking in cold circumstances.
The high tenacity engine hood creates a safer and bigger space of maintenance.
Three-layer steel wire tube makes long service life.
Double air filter to prolong the service life of the engine.
All the pin and bush are made of the top steel grades in steel production :Bearing Steel.
4.Production lines of MCLLROY Wheel Loader
A complete production process mainly includes: material procurement-steel plate cutting-welding-spray painting -drying-assembly-inspection
Steel plate cutting:
The cutting of the steel plate is closely related to the drawing design, workers' technique and cutting equipment.
Normally there are three types of cutting machines, you can see from the pictures here.
Flame cutting is used for iron plates over 40mm thick.
While plasma cutting is for steel plate that in between 20-40mm.
Laser cutting is for steel plate between 8-20mm.
It is great for cutting that requires high precision. For example, cutting steel components for bumper, hood, and driver's cab. The advantages of laser cutting are: low temperature, so the plate is not likely deformed; the disadvantage is that it consumes a lot of power.
When the steel sheet is uneven or the cutting speed is not steady, a melting point or break-point will form; so during the cutting process, workers need to go back and forth to check.
